CUSTOM MILITARY-GRADE LCDS
Made to Order for Harsh, Rugged and Military Environments
Are you baffled, confused or even bemused by all the LCD’s on the market and don’t have enough spare time to wade through the cacophony of data sheets!
Talk to us about your requirements for a rugged LCD. We have a lot of technical experience and work with the best suppliers in the market with a wide range of offerings, customisation services and great long term support.
The Vartech and Core Systems comprehensive line of rugged LCD displays are engineered to handle the most extreme of environments. Core Systems offers several different form factors (pull-out drawer and fixed mount) in order to satisfy the requirements of 72U fixed racks and mobile transit cases.
The advantage here is the low volume customisation we can implement.
The rugged MPM7 is a rugged 7 inch widescreen LCD with a full on screen display (OSD) and 8-button USB keypad on the front bezel.
- Anti-reflective glass with a native resolution of 1920 x 1080
- Shock-mounted and tested to meet DO-160E standards.
- Utilises 3U height and has a max weight of three pounds.
The rugged MPM12 is a rugged 12″ LCD with a full OSD.
- The MPM12 is built with anti-reflective glass and has a native resolution of 1280 x 800.
- Shock-mounted and tested to meet DO-160E standards.
- Utilises 5U height and has a max weight of four pounds.
The MPN17 by Core Systems is a rugged 17 inch panel mount LCD with 8U Height.
- The screen is built with anti-reflective glass and has a native resolution of 1280 x 1024.
- 8 or 16-port integrated KVM.
- Shock-mounted and has been tested to meet DO-160E standards.
- The MPN17 utilises 8U height and is less than 2 inches deep.
The rugged MP19W is a rugged 19” custom panel mount LCD that can be modified to meet your specifications.
- Utilises 8U height and is less than 3 inches deep.
- Optically-bonded anti-reflective glass with a native resolution of 1440 x 900.
- Includes 8 or 16 port integrated KVM.
The MP20 by Core Systems is a 20 inch ruggedised Rackmount LCD with 8U Height.
- Built with anti-reflective glass and has a native resolution of 1600 x 1200.
- Full on-screen display (OSD) and 8 or 16-port integrated KVM.
- The Rugged MP20 is shock-mounted and has been tested to meet DO-160E standards.
- Utilises 8U height and is less than 2 inches deep.
The rugged MPM24 LED Display from Core Systems is an industry-leading MIL-SPEC LCD designed for mounting in-vehicle/trailer.
- Can be mounted on a rack and optionally desk/bulk mounting.
- Includes integrated stereo speakers and a 1920 x 1200 max resolution.
- The SWaP-Optimised MPM24 is 22 inches tall and 3 inches deep.
RUGGED M1U-22
The rugged M1U-22 portable computer is a 1U 22″ depth all-in-one integrated computer with a 17″ HD display and keyboard.
- Pull-Out 17″ Display
- The M1U-22 has 1U short-depth design
- Includes the latest Intel Quad-Core processors.
- Includes sealed integrated USB keyboard with a touchpad.
- Application-Specific
- Military-Grade Design
The rugged G219 from Core Systems is an industry leading 19” rackmount LCD in a 1U form factor and has been tested to meet military standards.
- Clamshell display configuration with an integrated kill switch for all onboard electronics
- Reinforced quick-release cable retention arm
- 19” display with a native pixel resolution of 1280 x 1024
- DVI and VGA input
The ML-1925 1U 19″ Layflat LCD from Core Systems is fully rugged and ready for military use.
- Clamshell 19” display with a native pixel resolution of 1280 x 1024.
- Reinforced quick-release cable retention arm.
- Hulapoint pointing device.
- 4 or 8-port KVM for use with multiple computers in a single rack.
- DVI and VGA input.
- Anti-reflective glass.
The rugged 2U MLD-2 is a rugged rackmount LCD with side-by-side Dual 19″ LED Displays that has been tested to meet military standards.
- Dual 19” display
- Native pixel resolution of 1280 x 1024
- Anti-reflective glass.
- Utilises 2U heigh
- Less than 20 inches deep.
- 2x HD Displays
- Application-Specific Design
- Military-Grade Design
The rugged MLD2K from Core Systems features dual 19″ LCD displays in a side-by-side configuration.
- Dual 19″ displays with a native pixel resolution of 1280 x 1024.
- Includes independent DVI and VGA inputs.
- Options for A/R protective glass, EMI filters, and a resistive or capacitive touchscreen.
- Utilises 2U height and is 28 inches deep.
The rugged MLD-3 is a 3U Rackmount LCD with Triple 19″ LED Displays and is tested to perform in the harshest environments the military is faced with.
- 3x 19” displays with a native pixel resolution of 1280 x 1024.
- 3x inputs for both DVI-D and VGA signals.
- When all three monitors are fully extended, the MLD3K provides a true panoramic viewing experience.
- Utilises 3U height and is 20 inches deep.
The rugged MLD-3K is a triple 19” LCD in a short 3U form factor.
- 3x 19” displays with a native pixel resolution of 1280 x 1024.
- 3x inputs for both DVI-D and VGA signals.
- Sealed full travel keyboard, and an integrated touchpad or trackball pointing device.
ALL-WEATHER MONITORS & PANEL COMPUTERS
8.4” – 21.5” Screen sizes
All-Weather Touchscreen Monitors and Flat Panel Computers Built with a Solid State Design and IP67 Protection.
VarTech’s All-Weather All-Terrain touchscreen monitors and panel computers are built with industrial-grade components. The very robust enclosure is milled from billet 6061 Aircraft Aluminium and offers a slim profile with many standard core features and options.
Constructed to IP67 specifications, these fully-sealed All-Weather/All-Terrain displays and panel PC’s are protected from the ingress of dust and water, including temporary submersion. Designed to meet MIL-STD/MIL-Spec specifications for wide temperature ranges, shock and vibration protection, EMI protection and direct sunlight conditions are available.
DIAMONDVUE MONITORS & PANEL COMPUTERS
6.5” – 43” Screen sizes
VarTech’s flagship DiamondVue Series of touchscreen monitor displays and flat panel computers are available in various mechanical/mounting designs and sizes.
The adaptive design of DiamondVue monitors and panel computers enables the same mechanical footprint for standalone displays and panel computers alike, expanding versatility to a wider range of industrial, commercial, and military applications. New clip mount bezel options offer a slimmer design, and displays are easily mounted without having to drill holes. Expanded large and wide format screen sizes allow operators to have improved visibility and operability of HMI functions and process control.
TOUGHSTATION MONITORS & PANEL COMPUTERS
10.4” – 43” Screen sizes
VarTech’s industrial-grade, gasket sealed ToughStation Series of monitors and panel computers are available in 10.4″ to 43″ screen sizes and constructed of 316-stainless steel or black powder-coat aluminium.
The rugged display’s fully-sealed enclosure is corrosion and moisture resistant for use in work environments that require frequent washdowns and chemical sanitation.
This series is available with several powerful embedded computer options for continuous use in demanding HMI processes throughout many industrial applications. Shock and vibration resilient components and harnessed cables reduce strain on internal parts yielding additional ruggedness to the overall design.
15″ – IP67 PROTECTED MAN-PORTABLE COMPUTER FOR USE IN MILITARY APPLICATIONS
VarTech’s 15″ rugged all-in-one computer system designed to support mission-critical field and ground-mobile applications.
This man-portable panel computer system is intended specifically for use in rugged military and blue light environments. Constructed to IP67 specifications, the computer can be deployed to support mission operations including access to satellite communication systems, field surveillance, enhanced situational awareness and target acquisition radar.
Built to rugged MIL-Spec specifications
The units can be manufactured with either an embedded or removable computer. The FieldStation can also be built to your specifications with up to 3, 1 × 6 function keypad switches embedded in the bezel and up to 8 (including power), MIL-DTL 38999 I/O connectors in the rear of the unit.
COTS MILITARY MONITORS AND PANEL PCS FOR MISSION CRITICAL APPLICATIONS
Military grade COTS monitor, and panel computer products built for mission critical military and defence applications.
VarTech’s COTS military grade monitors and panel computers are built to conform with demanding military specifications (MIL-SPEC) guidelines. These rugged military grade display products are designed for use in mission critical battlefield vetronics in ground mobile, avionics and naval applications.
Environmental and functional upgrade packages are available for military and defence applications on land, at sea or in the air.
These upgrades are also available for non-military applications requiring night vision systems or EMI shielding such as the automotive industry, law enforcement and search and rescue.
MARINE GRADE MONITORS AND PANEL COMPUTER’S FOR MARITIME APPLICATIONS
Marine grade monitors and panel computers built to withstand all weather and temperature conditions of harsh marine environments.
VarTech manufacture a variety rugged all-weather displays and panel computers for use in harsh maritime applications. These marine grade display products provide maximum protection against wet and dirty work environments. Robust features such as IP67 waterproof enclosures, high bright sunlight readable screens, fully range dimming and shock & vibration resistant components further insure uninterrupted operation in marine environments.
VarTech marine grade displays are available with several touchscreen technologies, making them suitable for bridge control, navigation, monitoring/surveillance and ship automation. These Marine grade LCD Displays are the best choice for open cockpits, fly bridges, bright pilothouses, and other applications requiring protection against harsh marine conditions.
Our customers have a high-cost of failure so value the product advice and professional services that our company provides.
They cannot afford downtime and seek to engineer solutions that are reliable and predictable throughout the life-cycle of the deployed equipment.
At Unitronix, we understand these requirements in detail.
