Rugged Mission Computing
MILITARY-GRADE TACTICAL SYSTEMS
Core Systems specialises in providing military-grade lightweight computers that are designed for optimal performance in extreme weather conditions and high shock/vibration zones. These ruggedised computers are conduction-cooled and fully-sealed.
One Stop Systems Cernis and Donati products combine in many ways to satisfy a variety of AI processing missions. In 360-degree Situational Awareness (360SA) applications, Donati can be deployed in a backpack or vehicle mounted. Donati-SC acts as a sensor concentrator unit and Donati-MC serves as a GPU accelerated mission computer to serve real time fused video and sensor data to ground forces so nothing is missed outside the vehicle, day or night. With a single Cernis as the centerpiece of the 360SA system, a vehicle mounted system can scale to four Donati SC (front, rear, left, right) and four Donati MC to provide a full 360SA system for members of the vehicle crew.
DONATI
This rugged embedded sensor-fusion computer is powered by the NVIDIA AGX Orin, and designed to ingest and process data from a wide range of video and sensor inputs at the edge. Supports up to 6x GMSL2, CoaXPress, HD-SDI, NTSC, USB, or PCIe inputs.
- 6x configurable BUS ports
- AI processing on NVIDIA AGX Orin
- IP67-rated
DONATI-SC
This rugged embedded sensor-fusion computer is powered by the NVIDIA AGX Orin, and designed to ingest and process data from a wide range of video and sensor inputs at the edge. Supports up to 8x GMSL2, CoaXPress, HD-SDI, NTSC, USB, or PCIe inputs.
- 8x configurable BUS ports
- AI processing on NVIDIA AGX Orin
- IP67-rated
CERNIS
This rugged PCIe 4.0 switch forms the keystone of an expandable edge-AI mission computing system.
- 8x PCIe 4.0 ports
- AI processing on NVIDIA AGX Orin
- IP67-rated
RUGGED AR1
The AR1 is a small, rugged, and SWaP optimised tactical mission computer with the latest Intel Gen Quad Core CPU.
- Fully conduction-cooled
- Allows for the addition of up to two internal cards (1553, GPS, D/A, etc) for expanded I/O capability
- Utilises proprietary thermal transfer technology to cool the system without the use of moving parts
- Completely sealed chassis built to survive extreme temperature, shock and vibration
RUGGED AR2
The AR2 is a small, rugged, and SWaP-optimised tactical mission computer with the latest Intel Gen Quad Core CPU.
- Fully conduction-cooled
- Allows for the addition of up to four internal cards (1553, GPS, D/A, etc) for expanded IO capability
- Utilises proprietary thermal transfer technology to cool the system without the use of moving parts
- Completely sealed chassis built to survive extreme temperature, shock, and vibration
RUGGED AR3
The AR3 is a small, rugged, and SWaP-optimised tactical mission computer with the latest Intel Quad Core CPU.
- Fully conduction-cooled and allows for the addition of internal cards for expanded IO capability.
- Utilises proprietary thermal transfer technology to cool the system without the use of moving parts.
- Completely sealed and is built to survive extreme temperature, shock, and vibration.
RUGGED AR4
The AR4 is a small, rugged, and SWaP-optimised tactical computer with the latest Gen Quad Core CPU.
- Fully conduction cooled and with room for up to four internal cards (1553, GPS, D/A, etc) for expanded IO capability.
- Utilises proprietary thermal transfer technology to cool the system without the use of moving parts.
- Completely sealed chassis built to survive extreme temperature, shock, and vibration
RUGGED AR5
The Rugged AR5 tactical mission computer from Core Systems is fully sealed and conduction cooled. The AR5 has one removable sealed tray for CPU and SSD drive. It also includes 38999 MIL-Circular connectors for I/O and power.
- Latest Intel® Chipset technology with 1.91GHz max clock speed.
- Tested to meet MIL-STD-810G & DO-160G Shock, Vibration, Thermal, Altitude, and Humidity.
- 2x USB 3.0 and two USB 2.0 ports support keyboard, mouse, and other devices.
- IncludesRS-232 port, three 8254 timer/counters, and I2C support.
- 8x Gigabit Ethernet (GbE) ports with remote boot support and PoE functionality.
RUGGED AR5D
The Rugged AR5D tactical mission computer from Core Systems has two independent Red/Black systems that are fully sealed and conduction cooled.
- Includes the latest Intel® Chipset technology with dual 1.91GHz Quad-core CPUs.
- Each of the independent computers has two USB 2.0 and one USB 3.0 port to support the keyboard, mouse, and other devices.
- 3x 8254 timer/counters, and I2C support.
- 8x Gigabit Ethernet (GbE) ports on each computer with remote boot support and PoE support.
- Each system has integrated Intel HD Graphics with DisplayPort output (DP++).
RUGGED AR7
The AR7 is a small, rugged, and SWaP optimised tactical mission computer with the latest Intel Gen Quad Core CPU.
- Fully conduction-cooled
- Small Form Factor (SFF)
- Utilises proprietary thermal transfer technology to cool the system without the use of moving parts
- Completely sealed chassis built to survive extreme temperature, shock, and vibration
RUGGED AR8
The AR8 is a small, rugged, and SWaP optimised Cross-Domain Solution built for extreme environments.
- Fully conduction-cooled
- Small Form Factor (SFF)
- Utilises proprietary thermal transfer technology to cool the system without the use of moving parts
- Completely sealed chassis built to survive extreme temperature, shock, and vibration
RUGGED PCC
The rugged PCC01 Mission Computer from Core Systems is a rugged custom-built sealed fanless tactical computer build for the military.
- Extended temperature design with a range of -40C to +85C.
- Tested for MIL-S-901D Shock, MIL-STD-167-1 Vibration, MIL-STD-810G Shock & Vibration, MIL-STD-810F Humidity, and MIL-STD-461E/F EMC.
- Includes a 500GB solid-state drive which is installed in a removable carrier.
- Application-Specific
- Military-Grade Design
Edge Server Node
ATMOS Tactical Servers
Explore Core Systems’ Tactical Edge Server Line. The ATMOS2 is the most powerful, compact, lightweight, edge computer in the industry with up to 144 Xeon CPU Cores per server. The ATMOS is the only tactical computer with a built-in Battery Backup UPS and stackable chassis rail system. The ATMOS edge server is also the only tactical edge node to meet MIL-STD-810 Specs at the chassis level without the use of an external transit case.
Explore Core Systems’ Tactical Edge Server Line. The ATMOS2 is the most powerful, compact, lightweight, edge computer in the industry with up to 144 Xeon CPU Cores per server. The ATMOS is the only tactical computer with a built-in Battery Backup UPS and stackable chassis rail system. The ATMOS edge server is also the only tactical edge node to meet MIL-STD-810 Specs at the chassis level without the use of an external transit case.
