VPX ATR Systems
Rugged ATR chassis include conduction cooled VPX, air cooled VPX and liquid cooled VPX ATR solutions. All ATR chassis are designed for plug in cards in alignment with the SOSA technical standard. LCR engineers apply advanced design methods that continue to ensure field proven performance in mission critical defence applications in the most extreme environments.
VITA 48.2 Advanced Thermal Solutions
100 Series AoC3U-100 is a robust packaging solution which be be used for sensor applications where high speed RF and optical processing payload modules are deployed in EW / ISR operations and a range of radar applications. It is also designed to enable airborne, dismounted, mounted usage for many critical defence applications.
The AoC3U-210 chassis is a rugged packaging solution addressing a wide range of EW / ISR applications as well as high speed edge computing requirements. It’s compact and lightweight design is ideal for ground and airborne assets where size constraints and functional performance in demanding environments are key. Designed for 3U VPX and SOSA aligned payload cards supporting high speed connectivity with GbE, 10GbE, RF and optical interfaces.
Designed for 3U VPX and SOSA aligned modules, the AoC3U-412 is a 4 slot ATR chassis featuring dual removable high capacity drive bays. The conduction cooled chassis includes forced air cooling to widely available VITA 48.2 board sets with aggregate power demands of up to 400W. This rugged packaging solution addresses air, land and sea applications in demanding environments.
The AoC3U-410 is a 4 slot chassis designed for 3U VPX and SOSA aligned board payloads. It’s hybrid cooling design combines conduction cooling with forced air to stretch the thermal performance of readily available VITA 48.2 conduction cooled modules. This rugged chassis is intended for applications in demanding environments where SWaP constraints meet exceptional power demands.
The LoC3U-510 is intended for high performance VPX systems where aggregate payload power exceeds 600W. The chassis is designed for plug in cards in alignment with the SOSA technical standard. It’s hybrid cooling design stretches the cooling capabilities in equipment built with readily available VPX, VITA 48.2 conduction cooled modules. The chassis is ideal for applications where SWaP constraints meet exceptional power demands.
The AoC3U-610 is a 6 slot chassis for 3U VPX and SOSA aligned board payloads. It combines conduction cooling with forced air to stretch the thermal performance of readily available VITA 48.2 conduction cooled modules. This rugged chassis is intended for mission critical applications with higher functional requirements in demanding environments.
Designed for 3U VPX and SOSA aligned modules, the AoC3U-821 is an 8 + 2 slot ATR chassis featuring a removable high capacity drive bay. The conduction cooled chassis includes forced air cooling to widely available VITA 48.2 board sets with aggregate power demands of up to 700W. This rugged packaging solution addresses air, land and sea applications in demanding environments.
The AoC3U-1440 chassis provides exceptional cooling for widely available VPX and SOSA aligned 3U VITA 48.2 conduction cooled board sets with aggregate power demands of up to 850W. This precision engineered packaging solution is intended for mission critical air, land or sea defence applications. Its rugged design is targeted for harsh environments where failure is not an option.
